| Gyártói megnevezés: | ST6-R3-K03U-030 |
| Gyártói cikkszám: | R412022869 |
| Szín: | FEKETE |
| Cikkszám: | EMERSON-3 |
| Megnevezés teljes név: | Mágneses mező érzékelő ST6-R3-K03U-030 |
Specifications
Direct mounting for series
PRE, GPC, CCI, KPZ, PRA, SSI, CVI
Indirect mounting for series
TRR, CCL-IS, ICM, CSL-RD, ICS-D2, ITS, TRB, MNI, RPC, KHZ
Slot width
6 mm T-slot
Cable
with cable
Type of contact
Reed
Hysteresis
? 0,2 mT
Switching capacity
Reed, 3-pin: max. 6 W
Certificates
cULus, CE declaration of conformity, RoHS, UL (Underwriters Laboratories)
Protection class
IP65, IP67, IP69K
Min. ambient temperature
-30 °C
Max. ambient temperature
80 °C
Voltage drop U at Imax
I*Rs
DC switching current, max.
0.3 A
AC switching current, max.
0.5 A
Max. switching frequency
400 Hz
Switching point precision
±0,1 mT
Switching logic
NO (make contact)
LED status display
Yellow
Electrical connection
open cable ends
Number of poles
3-pin
Operating voltage DC, min.
10 V DC
Operating voltage DC, max.
30 V DC
Operating voltage AC, min.
10 V AC
Operational voltage AC, max.
30 V AC
Short circuit resistance
Protected against polarity reversal
