SMARTGUARD-63A-S0 Teljes otthoni tartalék, nincs szükség további kapcsolószekrényre ? 20 ms ultra gyors váltás a tartalék üzemmódra Megkerülő üzemmód biztosítása hiba esetén Intelligens terhelésvezérlés beépített EMMA-val Dimensions (W x H x D) 600 mm × 170 mm × 490 mm Weight (not including mounting plate ) 17 kg Performance AC Voltage (Nominal) 380/400/415V, 220/230/240V, L1/L2/L3/N+PE Max. current (from/to Grid) 63 A Max. current (from/to Inverter) 60 A Max. current (to Backup Load) 63 A Max. current(to Non-BackupLoad) 1 63 A Low-Voltage ride-through Supported Switchover time ? 20ms (MAP0), ? 100ms (M1/MB0) 2 Bypass operation mode Manual DG mode Remote control Interface Power output 9.5–13.2V @ 100mA, ? 3m LAN 10/100Mbps, ? 100m WAN 10/100Mbps, ? 100m WLAN AP Mode, 802.11b/g/n (2.412GHz–2.484GHz) RS485 9600/19200/115200bps,× 2, ? 50m Digital input ×2, ? 20m; Avtive port 3 Digital output ×2, ? 20m DG Do Port Passive Port, 1-100mA ?24V ATS Need prepare the ATS, which supports automatic control and automatic switch-in and reset. Measurement Range Current range ? 63 A Energy accuracy ± 1% Device Management Smart energy controllers up to 3 Smart chargers up to 2 Heat pump up to 14 Shelly device up to 20 Environment Cooling Natural Convection Relative humidity range 5%-95% RH (non condensing) Max. operating altitude 4000m (derated over 2000m) Degree of protection IP55 Operating temperature range -25°C–50°C 5 Compatible Device Smart energy controller SMax. 3 inverters supported in parallel connection (MAP0) Max. 1 inverter supported (M1/MB0) Smart charger SCharger–7KS/22KT–S0 Heat pump SG-ready Shelly device Shelly Plus Plug S, Shelly Plus 2PM, Shelly Pro 2PM
