Megnevezés teljes név | Alkonykapcsoló azh-mini-LED |
Cikkszám | RSAZHMINILED |
Gyártói cikkszám | AZH-MINI-LED |
Gyártói megnevezés | AZH-MINI-LED 230V, 16A inrush |
Leírás: AZH-MINI-LED 230V, 16A inrush
Alkonykapcsoló, falra szerelhető 16A, inrush 1NO, beépített fényérzékelővel
Power supply voltage 100÷265 V AC
Power supply tolerance -10 ÷ 10 %
Maximum AC-1 load current 16 A
The executive element relay
Contact configuration 1 × NO
Separation of the contact NO
Resistance to shock currents 160 A/20 ms
Operating threshold - adjustable 2 ÷ 1000 Lx
Hysteresis ok. 15 Lx
Delay of switching on ok. 10 s
Delay of tripping operation ok. 20 s
Terminal OMY 2×1 mm2, l: 0.8 m
Power consumption 0,6 W
Working temperature -25 ÷ 50 °C
Dimensions 42×64×30 mm
Assembly on wall
Ingress Protection Marking IP65 - hermetic
|
